DSC1001BE1-125.0000T Microchip

Please contact us for more photos of DSC1001BE1-125.0000T

Part Number	DSC1001BE1-125.0000T
Manufacturer	Microchip
Quantity in stock	599030 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	Silicon Oscillator 125MHz 1.8V 3.3V 15pF 4-Pin QFN T R
Category	Logic & Timing IC
Family	SMD Crystal Oscillator
ROHS Compliant	Yes
MSL Level	DSC1001BE1-125.0000T
Datasheet download	DSC1001BE1-125.0000T.pdf

Request Quotation for DSC1001BE1-125.0000T

DSC1001BE1-125.0000T Specifications

Part Number	DSC1001BE1-125.0000T
Frequency Stability	±50 ppm
Maximum Symmetry	55 %
Mounting	Surface Mount
Type	MEMS
Lead Finish	Gold Over Nickel Palladium
Package Dimensions	5 x 3.2 x 0.85 mm
Pin Count	4
Operating Temperature	-20 to 70 °C
Supplier Package	QFN
Frequency Aging
Operating Supply Voltage
Category
Load Capacitance
Rad Hard	No
Maximum Processing Temperature	260 °C
Standard Frequency	125 MHz
Output Level	CMOS
Moisture Sensitivity Level	1
Package	4QFN
Replacement Part Number	PART-DSC1001BE1-125.0000T
Weight	Contact us
Country of Origin	-
