Please contact us for more photos of 0537480308
| Part Number | 0537480308 |
|---|---|
| Manufacturer | Molex |
| Quantity in stock | 212760 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Board to Board PL 30 POS 0.5mm Solder ST SMD Embossed T R |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 0537480308 |
| Datasheet download |  0537480308.pdf |
| Part Number | 0537480308 |
|---|---|
| Termination Method | Solder |
| Housing Color | White |
| Mounting | Surface Mount |
| Product Dimensions | 11.3 x 4.3 x 2.4 mm |
| Operating Temperature | -40 to 105 °C |
| Contact Material | Brass |
| Body Orientation | Straight |
| Housing Material | Liquid Crystal Polymer |
| Gender | PL |
| Contact Plating | Gold Over Nickel |
| Pitch | 0.5 mm |
| Rad Hard | No |
| Lead Finish | Gold |
| Product Depth | 4.3 mm |
| Product Height | 2.4 mm |
| Product Length | 11.3 mm |
| Replacement Part Number | PART-0537480308 |
| Weight | Contact us |
| Country of Origin | - |
