Please contact us for more photos of 145046120645829+
| Part Number | 145046120645829+ |
|---|---|
| Manufacturer | AVX |
| Quantity in stock | 597770 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Fine Pitch Connector M 120 POS 0.5mm Solder ST SMD T R |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 145046120645829+ |
| Datasheet download |  145046120645829+.pdf |
| Part Number | 145046120645829+ |
|---|---|
| Pitch | 0.5 mm |
| Lead Finish | Gold |
| Rad Hard | No |
| Product Dimensions | 35.5 x 4.8 x 3.8 mm |
| Operating Temperature | -25 to 85 °C |
| Termination Method | Solder |
| Mounting | Surface Mount |
| Contact Plating | Gold |
| Contact Material | Copper alloy |
| Gender | RCP |
| Body Orientation | Straight |
| Housing Material | Heat-resistant plastic |
| Product Depth | 4.8 mm |
| Product Height | 3.8 mm |
| Product Length | 35.5 mm |
| Replacement Part Number | PART-145046120645829+ |
| Weight | Contact us |
| Country of Origin | - |
