Please contact us for more photos of UVZ1V222MHD
| Part Number | UVZ1V222MHD |
|---|---|
| Manufacturer | Nichicon |
| Quantity in stock | 471180 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Aluminum 2200uF 35V 20% (16 X 25mm) Radial Aluminum Cylindrical Can 7.5mm 1260mA 1000 hr 105\u00b0C Bulk |
| Category | Capacitors |
| Family | Capacitor Aluminum |
| ROHS Compliant | Yes |
| MSL Level | UVZ1V222MHD |
| Datasheet download |  UVZ1V222MHD.pdf |
| Part Number | UVZ1V222MHD |
|---|---|
| Operating Temperature | -55 to 105 °C |
| Rad Hard | No |
| Max Processing Temp | 260 |
| Product Dimensions | 25 mm |
| Ripple Current | 1260 mA |
| Termination Style | Radial |
| Tolerance | 20 % |
| Lead Finish | Matte Tin |
| Leakage Current | 2310@1Min|770@2Min uA |
| Construction | Aluminum Cylindrical Can |
| Package/Case | 16 X 25 |
| Lead Pitch For Radial | 7.5 mm |
| Voltage(DC) | 35 V |
| Capacitance Value | 2200 uF |
| Mounting | Through Hole |
| Product Diameter | 16 mm |
| Product Height | 25 mm |
| Replacement Part Number | PART-UVZ1V222MHD |
| Weight | Contact us |
| Country of Origin | - |
