Please contact us for more photos of APSC6R3ELL821MJB5S
| Part Number | APSC6R3ELL821MJB5S |
|---|---|
| Manufacturer | Nippon ChemiCon |
| Quantity in stock | 168130 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Aluminum 820uF 6.3V \u00b120% (10 X 11.5mm) Radial Aluminum Cylindrical Can 5mm 0.007 Ohm 6640mA 15000hr 105\u00b0C Bulk |
| Category | Capacitors |
| Family | Capacitor Aluminum |
| ROHS Compliant | Yes |
| MSL Level | APSC6R3ELL821MJB5S |
| Datasheet download |  APSC6R3ELL821MJB5S.pdf |
| Part Number | APSC6R3ELL821MJB5S |
|---|---|
| Termination Style | Radial |
| Voltage(DC) | 6.3 Vdc |
| Mounting | Through Hole |
| Package/Case | 10 X 11.5 |
| Leakage Current | 1030@2Min uA |
| Lead Pitch For Radial | 5 mm |
| Rad Hard | No |
| Pin Count | 2 |
| Operating Temperature | -55 to 105 °C |
| Supplier Package | Radial |
| Package Dimensions | 10 x 11.5 mm |
| Equivalent Series Resistance | 0.007 Ohm |
| Lead Finish | Tin |
| Maximum Processing Temperature | 260 °C |
| Capacitance Value | 820 uF |
| Construction | Aluminum Cylindrical Can |
| Lifetime | 15000 hr |
| Ripple Current | 6640 mA |
| Tolerance | ±20 % |
| Product Diameter | 10 mm |
| Product Height | 11.5 mm |
| Replacement Part Number | PART-APSC6R3ELL821MJB5S |
| Weight | Contact us |
| Country of Origin | - |
