Please contact us for more photos of EKMG500ELL1R0ME11D
| Part Number | EKMG500ELL1R0ME11D |
|---|---|
| Manufacturer | Nippon ChemiCon |
| Quantity in stock | 273310 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Aluminum 1uF 50V \u00b120% (5 X 11mm) Radial Aluminum Cylindrical Can 2mm 13mA 1000hr 105\u00b0C Bulk |
| Category | Capacitors |
| Family | Capacitor Aluminum |
| ROHS Compliant | Yes |
| MSL Level | EKMG500ELL1R0ME11D |
| Datasheet download |  EKMG500ELL1R0ME11D.pdf |
| Part Number | EKMG500ELL1R0ME11D |
|---|---|
| Ripple Current | 13 mA |
| Leakage Current | 1.5@1Min uA |
| Construction | Aluminum Cylindrical Can |
| Lifetime | 1000 hr |
| Tolerance | ±20 % |
| Capacitance Value | 1 uF |
| Package/Case | 5 X 11 |
| Voltage(DC) | 50 Vdc |
| Lead Finish | Tin|Bismuth |
| Lead Pitch For Radial | 2 mm |
| Termination Style | Radial |
| Pin Count | 2 |
| Maximum Processing Temperature | 260 °C |
| Operating Temperature | -55 to 105 °C |
| Package Dimensions | 5 x 11 mm |
| Supplier Package | Radial |
| Mounting | Through Hole |
| Rad Hard | No |
| Product Diameter | 5 mm |
| Product Height | 11 mm |
| Replacement Part Number | PART-EKMG500ELL1R0ME11D |
| Weight | Contact us |
| Country of Origin | - |
