Please contact us for more photos of EKXG451EC3220ML20S
| Part Number | EKXG451EC3220ML20S |
|---|---|
| Manufacturer | Nippon ChemiCon |
| Quantity in stock | 577050 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Aluminum 22uF 450V \u00b120% (16 X 20mm) Radial Aluminum Cylindrical Can 7.5mm 290mA 8000hr 105\u00b0C Bulk |
| Category | Capacitors |
| Family | Capacitor Aluminum |
| ROHS Compliant | Yes |
| MSL Level | EKXG451EC3220ML20S |
| Datasheet download |  EKXG451EC3220ML20S.pdf |
| Part Number | EKXG451EC3220ML20S |
|---|---|
| Construction | Aluminum Cylindrical Can |
| Tolerance | ±20 % |
| Package Dimensions | 16 x 20 mm |
| Lifetime | 8000 hr |
| Leakage Current | 496@1Min|223@5Min uA |
| Mounting | Through Hole |
| Termination Style | Radial |
| Pin Count | 2 |
| Package/Case | 16 X 20 |
| Ripple Current | 290 mA |
| Rad Hard | No |
| Operating Temperature | -25 to 105 °C |
| Capacitance Value | 22 uF |
| Voltage(DC) | 450 Vdc |
| Supplier Package | Radial |
| Maximum Processing Temperature | 260 °C |
| Lead Pitch For Radial | 7.5 mm |
| Lead Finish | Tin |
| Product Diameter | 16 mm |
| Product Height | 20 mm |
| Replacement Part Number | PART-EKXG451EC3220ML20S |
| Weight | Contact us |
| Country of Origin | - |
