Please contact us for more photos of ECE-A1EN100UI
| Part Number | ECE-A1EN100UI |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 895610 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Aluminum 10uF 25V 20% (5 X 11mm) Radial 2.5mm 45mA 2000 hr 85\u00b0C Ammo Pack |
| Category | Capacitors |
| Family | Capacitor Aluminum |
| ROHS Compliant | Yes |
| MSL Level | ECE-A1EN100UI |
| Datasheet download |  ECE-A1EN100UI.pdf |
| Part Number | ECE-A1EN100UI |
|---|---|
| Package/Case | 5 X 11 |
| Product Dimensions | 11 mm |
| Ripple Current | 45 mA |
| Max Processing Temp | 250 to 260 |
| Mounting | Through Hole |
| Lifetime | 2000 hr |
| Leakage Current | 10.5@5Min uA |
| Capacitance Value | 10 uF |
| Lead Finish | Tin |
| Voltage(DC) | 25 V |
| Lead Pitch For Radial | 2.5 mm |
| Termination Style | Radial |
| Rad Hard | No |
| Tolerance | 20 % |
| Operating Temperature | -40 to 85 °C |
| Product Diameter | 5 mm |
| Product Height | 11 mm |
| Replacement Part Number | PART-ECE-A1EN100UI |
| Weight | Contact us |
| Country of Origin | - |
