Please contact us for more photos of EEFCD0J220ER
| Part Number | EEFCD0J220ER |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 601160 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Aluminum 22uF 6.3V 20% (7.3 X 4.3 X 1.8mm) SMD 0.04 Ohm 1600mA 1000 hr 105\u00b0C Embossed T R |
| Category | Capacitors |
| Family | Capacitor Aluminum |
| ROHS Compliant | Yes |
| MSL Level | EEFCD0J220ER |
| Datasheet download |  EEFCD0J220ER.pdf |
| Part Number | EEFCD0J220ER |
|---|---|
| Construction | Flat |
| Package/Case | 7.3 X 4.3 X 1.8 |
| Mounting | Surface Mount |
| Equivalent Series Resistance | 0.04 Ohm |
| Operating Temperature | -40 to 105 °C |
| Ripple Current | 1600 mA |
| Capacitance Value | 22 uF |
| Lead Finish | Tin |
| Voltage(DC) | 6.3 V |
| Product Dimensions | 7.3 x 4.3 x 1.8 mm |
| Max Processing Temp | 260 |
| Tolerance | 20 % |
| Rad Hard | No |
| Product Depth | 4.3 mm |
| Product Height | 1.8 mm |
| Product Length | 7.3 mm |
| Replacement Part Number | PART-EEFCD0J220ER |
| Weight | Contact us |
| Country of Origin | - |
| Image | Part Number and Brand | Brief Description and PDF Datasheet |
|---|---|---|
|
Panasonic | Cap Aluminum 330uF 2.5V 20% 2917 J-Lead Flat 0.0045 Ohm 8500mA 2000 hr 105\u00b0C Embossed Carrier T R Download PDF datasheet for EEFSX0E331E4.pdf |
|
Panasonic | Cap Aluminum 1000uF 100V 20% (18 X 35.5mm) Radial Aluminum Cylindrical Can 7.5mm 1300mA 2000 hr 85\u00b0C Bulk Download PDF datasheet for ECA2AM102.pdf |
|
Nippon ChemiCon | Cap Aluminum 150uF 10V \u00b120% (8 X 6.7mm) Cylindrical 0.027 Ohm 2800mA 15000hr 105\u00b0C Plastic T R Download PDF datasheet for APXA100ARA151MH70G.pdf |
|
Panasonic | Cap Aluminum 47uF 6.3V 20% (4 X 5.4mm) SMD 36mA 1000 hr 85\u00b0C T R Download PDF datasheet for EEE0JA470WR.pdf |
|
Panasonic | Cap Aluminum 1200uF 50V 20% (18 X 25mm) Radial 7.5mm 2610mA 5000 hr 105\u00b0C Ammo Pack Download PDF datasheet for EEUFC1H122SB.pdf |
|
Panasonic | Cap Aluminum 33uF 10V 20% (5 X 5.8mm) SMD 160mA 2000 hr 105\u00b0C T R Download PDF datasheet for EEEFK1A330R.pdf |
|
Nippon ChemiCon | Cap Aluminum 470uF 25V 20% (10 X 12.5mm) Radial Aluminum Cylindrical Can 5mm 380mA 2000hr 105\u00b0C Ammo Pack Download PDF datasheet for EKMQ250ETD471MJC5S.pdf |
|
Nichicon | Cap Aluminum 10uF 50V 20% (5 X 11mm) Radial 2mm 46mA 1000 hr 105\u00b0C Bulk Download PDF datasheet for UVZ1H100MDD.pdf |
|
Panasonic | Cap Aluminum 10uF 50V 20% (6.3 X 11.2mm) Radial 2.5mm 50mA 2000 hr 85\u00b0C Ammo Pack Download PDF datasheet for ECEA1HN100UI.pdf |
|
Panasonic | Cap Aluminum 220uF 400V 20% (25 X 40mm) 10mm 2030mA 3000 hr 105\u00b0C Bulk Download PDF datasheet for EETED2G221JJ.pdf |
