Part Number | ELJRF5N6DFB |
---|---|
Manufacturer | Panasonic |
Quantity in stock | 196390 Pieces |
Market Price | - |
Our Better Price | Send by email: [email protected] |
Delivery Time | 1 day (can ship today) |
Description | Ind High Frequency Chip Laser Cut 5.6nH 0.3nH 100MHz 8Q-Factor Ceramic 340mA 0402 T R |
Category | Inductor |
Family | Inductor Surface Mount |
ROHS Compliant | Yes |
MSL Level | ELJRF5N6DFB |
Datasheet download | ELJRF5N6DFB.pdf |
Part Number | ELJRF5N6DFB |
---|---|
Package/Case | 0402 |
Lead Finish | Tin |
Product Dimensions | 1.05 x 0.55 x 0.55 mm |
Technology | Laser Cut |
Rad Hard | No |
Max Processing Temp | 260 |
Tolerance | 0.3 nH |
Test Frequency | 100 MHz |
Operating Temperature | -20 to 85 °C |
Product Depth | 0.55 mm |
Product Height | 0.55 mm |
Product Length | 1.05 mm |
Replacement Part Number | PART-ELJRF5N6DFB |
Weight | Contact us |
Country of Origin | - |
