Please contact us for more photos of MCR03EZPFX6983
| Part Number | MCR03EZPFX6983 |
|---|---|
| Manufacturer | ROHM |
| Quantity in stock | 150160 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Res Thick Film 0603 698K Ohm 1% 1 10W \u00b1100ppm \u00b0C Molded SMD Paper T R |
| Category | Resistor |
| Family | Resistor Fixed Single-Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | MCR03EZPFX6983 |
| Datasheet download |  MCR03EZPFX6983.pdf |
| Part Number | MCR03EZPFX6983 |
|---|---|
| Resistance Value | 698 kOhm |
| Type | Thick Film |
| Pin Count | 2 |
| Rad Hard | No |
| Supplier Package | 0603 |
| Case Style | Molded |
| Termination Style | Wraparound |
| Mounting | Surface Mount |
| Case Size | 0603 |
| Package Dimensions | 1.6 x 0.8 x 0.45 mm |
| Maximum Processing Temperature | 260 °C |
| Tolerance | 1 % |
| Temperature Coefficient | ±100 ppm/°C |
| Operating Temperature | -55 to 155 °C |
| Lead Finish | Tin Over Nickel |
| Product Depth | 0.8 mm |
| Product Height | 0.45 mm |
| Product Length | 1.6 mm |
| Replacement Part Number | PART-MCR03EZPFX6983 |
| Weight | Contact us |
| Country of Origin | - |
