Please contact us for more photos of B82442H1105K000
| Part Number | B82442H1105K000 |
|---|---|
| Manufacturer | TDK |
| Quantity in stock | 710910 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Ind High Current Chip Molded 1mH 10% 252KHz 30Q-Factor Ferrite 120mA 2220 Blister T R |
| Category | Inductor |
| Family | Inductor Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | B82442H1105K000 |
| Datasheet download |  B82442H1105K000.pdf |
| Part Number | B82442H1105K000 |
|---|---|
| Rad Hard | No |
| MSL Level | 1 |
| Test Frequency | 252 kHz |
| Product Dimensions | 5.9 x 5.3 x 5.3 mm |
| Lead Finish | Tin |
| Package/Case | 2220 |
| Protection Style | Molded |
| Type | High Current Chip |
| Tolerance | 10 % |
| Core Material | Ferrite |
| Max Processing Temp | 260 |
| Product Depth | 5.3 mm |
| Product Height | 5.3 mm |
| Product Length | 5.9 mm |
| Replacement Part Number | PART-B82442H1105K000 |
| Weight | Contact us |
| Country of Origin | - |
