Please contact us for more photos of 1982676-1
| Part Number | 1982676-1 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 706320 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | AMP1982676-1 |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 1982676-1 |
| Datasheet download |  1982676-1.pdf |
| Part Number | 1982676-1 |
|---|---|
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Copper Alloy |
| Type | Wire to Board |
| Mounting | Through Hole |
| Maximum Current Rating | 15 A |
| Lead Free | Yes |
| Contact Plating | Gold Over Nickel |
| Number of Contacts | 12 |
| Maximum Voltage Rating | 250 Vac |
| Packaging | Tray|Box |
| Pitch | 1.5 mm |
| Operating Temperature | -30 to 105 °C |
| Body Orientation | Right Angle |
| Rad Hard | No |
| Number of Rows | 2 |
| Family | 1982676 |
| Gender | RCP |
| Termination Method | Solder |
| Housing Color | Black |
| Product Depth | 27.4 mm |
| Product Height | 10 mm |
| Product Length | 40 mm |
| Replacement Part Number | PART-1982676-1 |
| Weight | Contact us |
| Country of Origin | - |
