Please contact us for more photos of 36502A27NJTDG
| Part Number | 36502A27NJTDG |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 717190 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Ind High Frequency Chip Unshielded Wirewound 27nH 5% 250MHz 55Q-Factor 500mA 0805 T R |
| Category | Inductor |
| Family | Inductor Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | 36502A27NJTDG |
| Datasheet download |  36502A27NJTDG.pdf |
| Part Number | 36502A27NJTDG |
|---|---|
| Max Processing Temp | 245|260 |
| Test Frequency | 250 MHz |
| Protection Style | Unshielded |
| Operating Temperature | -40 to 125 °C |
| Technology | Wirewound |
| Rad Hard | No |
| Package/Case | 0805 |
| Product Dimensions | 2.29 x 1.73 x 1.52 mm |
| Tolerance | 5 % |
| Product Depth | 1.73 mm |
| Product Height | 1.52 mm |
| Product Length | 2.29 mm |
| Replacement Part Number | PART-36502A27NJTDG |
| Weight | Contact us |
| Country of Origin | - |
