| Part Number | ADS1259BIPWR |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 738320 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | ADC Single Delta-Sigma 14ksps 24-bit Serial 20-Pin TSSOP T R |
| Category | Data Conversion IC |
| Family | ADC |
| ROHS Compliant | Yes |
| MSL Level | ADS1259BIPWR |
| Datasheet download |  ADS1259BIPWR.pdf |
| Part Number | ADS1259BIPWR |
|---|---|
| Typical Dual Supply Voltage | ±2.5 V |
| Number of Analog Inputs | 1 |
| No Missing Codes | 24 Bit |
| Minimum Single Supply Voltage | 4.75 V |
| Voltage Supply Source | Single|Dual |
| Mounting | Surface Mount |
| Input Type | Voltage |
| Supplier Package | TSSOP |
| Input Voltage | ±2.5 V |
| Operating Temperature | -40 to 105 °C |
| Product Dimensions | 6.6 x 4.5 x 1.05 mm |
| MSL Level | 1 |
| Typical Single Supply Voltage | 5 V |
| Voltage Reference | Internal|External |
| Resolution | 24 Bit |
| Full Scale Error | 0.5 % of FSR |
| Pin Count | 20 |
| Sample and Hold | No |
| Number of ADCs | 1 |
| Rad Hard | No |
| Typical Power Dissipation | 13 mW |
| Integral Nonlinearity Error | 0.0003 % of FSR |
| Differential Input | Yes |
| Maximum Single Supply Voltage | 5.25 V |
| Single-Ended Input | No |
| Input Signal Type | Differential |
| Architecture | Delta-Sigma |
| Maximum Power Dissipation | 22 mW |
| Digital Interface Type | Serial (3-Wire, SPI) |
| Digital Supply Support | Yes |
| Polarity of Input Voltage | Bipolar |
| Max Processing Temp | 260 |
| Lead Finish | Gold |
| Sampling Rate | 14 ksps |
| Package | 20TSSOP |
| Replacement Part Number | PART-ADS1259BIPWR |
| Weight | Contact us |
| Country of Origin | - |
