Please contact us for more photos of CRCW120647R0JNEAHP
| Part Number | CRCW120647R0JNEAHP |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 537010 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Res Thick Film 1206 47 Ohm 5% 1 2W \u00b1200ppm \u00b0C Molded SMD SMD Paper T R |
| Category | Resistor |
| Family | Resistor Fixed Single-Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | CRCW120647R0JNEAHP |
| Datasheet download |  CRCW120647R0JNEAHP.pdf |
| Part Number | CRCW120647R0JNEAHP |
|---|---|
| Mounting | Surface Mount |
| Resistance Value | 47 Ohm |
| Lead Finish | Tin |
| Operating Temperature | -55 to 155 °C |
| MSL Level | 1 |
| Package Type | SMD |
| Failure Rate | |
| Military Standard | |
| Temperature Coefficient | ±200 ppm/°C |
| Product Dimensions | 3.1 x 1.6 x 0.5 mm |
| Rad Hard | No |
| Case Style | Molded |
| Max Processing Temp | 260 |
| Type | Thick Film |
| Tolerance | 5 % |
| Case Size | 1206 |
| Product Depth | 1.6 mm |
| Product Height | 0.5 mm |
| Product Length | 3.1 mm |
| Product Weight | 10 mg |
| Replacement Part Number | PART-CRCW120647R0JNEAHP |
| Weight | Contact us |
| Country of Origin | - |
