Please contact us for more photos of IHLP2020CZER3R3M01
| Part Number | IHLP2020CZER3R3M01 |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 740000 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Ind High Current Shielded Wirewound 3.3uH 20% 100KHz 5A 2020 T R |
| Category | Inductor |
| Family | Inductor Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | IHLP2020CZER3R3M01 |
| Datasheet download |  IHLP2020CZER3R3M01.pdf |
| Part Number | IHLP2020CZER3R3M01 |
|---|---|
| Product Dimensions | 5.74 x 5.43 x 3 mm |
| Protection Style | Shielded |
| Lead Finish | Tin |
| Package/Case | 2020 |
| MSL Level | 1 |
| Operating Temperature | -55 to 125 °C |
| Technology | Wirewound |
| Tolerance | 20 % |
| Rad Hard | No |
| Max Processing Temp | 260 |
| Type | High Current |
| Test Frequency | 100 kHz |
| Product Depth | 5.43 mm |
| Product Height | 3 mm |
| Product Length | 5.74 mm |
| Replacement Part Number | PART-IHLP2020CZER3R3M01 |
| Weight | Contact us |
| Country of Origin | - |
