IHLP4040DZER4R7M01 Vishay

IHLP4040DZER4R7M01 Images

Please contact us for more photos of IHLP4040DZER4R7M01

Part Number IHLP4040DZER4R7M01
Manufacturer Vishay
Quantity in stock 219850 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Ind High Current Shielded Wirewound 4.7uH 20% 100KHz 9.5A 4040 T R
Category Inductor
Family Inductor Surface Mount
ROHS Compliant Yes
MSL Level IHLP4040DZER4R7M01
Datasheet download IHLP4040DZER4R7M01.pdf
Request Quotation for IHLP4040DZER4R7M01

IHLP4040DZER4R7M01 Specifications

Part Number IHLP4040DZER4R7M01
Product Dimensions 11.22 x 10.3 x 4 mm
Technology Wirewound
Rad Hard No
Tolerance 20 %
Max Processing Temp 260
Type High Current
Test Frequency 100 kHz
MSL Level 1
Operating Temperature -55 to 125 °C
Package/Case 4040
Protection Style Shielded
Lead Finish Tin
Product Depth 10.3 mm
Product Height 4 mm
Product Length 11.22 mm
Replacement Part Number PART-IHLP4040DZER4R7M01
Weight Contact us
Country of Origin -
