Please contact us for more photos of M55342K12B12B1RTS
| Part Number | M55342K12B12B1RTS |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 273290 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Res Thin Film 0603 12.1K Ohm 0.1% 1 10W \u00b1100ppm \u00b0C Molded SMD T R |
| Category | Resistor |
| Family | Resistor Fixed Single-Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | M55342K12B12B1RTS |
| Datasheet download |  M55342K12B12B1RTS.pdf |
| Part Number | M55342K12B12B1RTS |
|---|---|
| Power Rating | 0.1 W |
| Military Standard | MIL-PRF-55342 |
| Max Processing Temp | 260 |
| Pin Count | 2 |
| Case Size | 0603 |
| Rad Hard | No |
| Case Style | Molded |
| Resistance Value | 12.1 kOhm |
| Tolerance | 0.1 % |
| Mounting | Surface Mount |
| Product Dimensions | 1.62 x 0.81 x 0.84(Max) |
| Lead Finish | Tin|Lead Over Nickel |
| Operating Temperature | -55 to 150 °C |
| Type | Thick Film |
| Supplier Package | 0603 |
| Package Type | SMD |
| Termination Style | Wraparound |
| Temperature Coefficient | ±100 ppm/°C |
| Product Depth | 0.81 mm |
| Product Height | 0.84(Max) mm |
| Product Length | 1.62 mm |
| Replacement Part Number | PART-M55342K12B12B1RTS |
| Weight | Contact us |
| Country of Origin | - |
