Please contact us for more photos of 0603YC682KAT2A
| Part Number | 0603YC682KAT2A |
|---|---|
| Manufacturer | AVX |
| Quantity in stock | 277420 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Ceramic 0.0068uF 16V X7R 10% SMD 0603 125\u00b0C Paper T R |
| Category | Capacitors |
| Family | Capacitor Ceramic Multilayer |
| ROHS Compliant | Yes |
| MSL Level | 0603YC682KAT2A |
| Datasheet download |  0603YC682KAT2A.pdf |
| Part Number | 0603YC682KAT2A |
|---|---|
| Dielectric | X7R |
| Product Dimensions | 1.6 x 0.81 x 0.86 mm |
| Construction | Flat |
| Case Style | Ceramic Chip |
| Capacitance Value | 0.0068 uF |
| Package/Case | 0603 |
| Case Size | 0603 |
| Rad Hard | No |
| Tolerance | 10 % |
| Operating Temperature | -55 to 125 °C |
| MSL Level | 1 |
| Voltage(DC) | 16 V |
| Mounting | Surface Mount |
| Max Processing Temp | 260 |
| Lead Finish | Matte Tin |
| Product Depth | 0.81 mm |
| Product Height | 0.86(Max) mm |
| Product Length | 1.6 mm |
| Replacement Part Number | PART-0603YC682KAT2A |
| Weight | Contact us |
| Country of Origin | - |
