Please contact us for more photos of NPIM74P8R2MTRF
| Part Number | NPIM74P8R2MTRF |
|---|---|
| Manufacturer | NIC Components |
| Quantity in stock | 176080 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Ind Power Shielded Wirewound 8.2uH 20% 100KHz Ferrite 4A T R |
| Category | Inductor |
| Family | Inductor Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | NPIM74P8R2MTRF |
| Datasheet download |  NPIM74P8R2MTRF.pdf |
| Part Number | NPIM74P8R2MTRF |
|---|---|
| Test Frequency | 100 kHz |
| Product Dimensions | 7.3 x 6.6 x 2.8 |
| Pin Count | 2 |
| Supplier Package | SMD |
| Technology | Wirewound |
| Max Processing Temp | 260 |
| Tolerance | 20 % |
| Package/Case | 7.3 X 6.6 X 2.8 |
| Lead Finish | Matte Tin |
| Rad Hard | No |
| Protection Style | Shielded |
| Operating Temperature | -40 to 125 °C |
| MSL Level | 1 |
| Product Depth | 6.6 mm |
| Product Height | 2.8 mm |
| Product Length | 7.3 mm |
| Replacement Part Number | PART-NPIM74P8R2MTRF |
| Weight | Contact us |
| Country of Origin | - |
