Please contact us for more photos of EKZH6R3ELL821MHB5D
| Part Number | EKZH6R3ELL821MHB5D |
|---|---|
| Manufacturer | Nippon ChemiCon |
| Quantity in stock | 548710 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Aluminum 820uF 6.3V \u00b120% (8 X 11.5mm) Radial Aluminum Cylindrical Can 3.5mm 0.062 Ohm 900mA 6000hr 105\u00b0C Bulk |
| Category | Capacitors |
| Family | Capacitor Aluminum |
| ROHS Compliant | Yes |
| MSL Level | EKZH6R3ELL821MHB5D |
| Datasheet download |  EKZH6R3ELL821MHB5D.pdf |
| Part Number | EKZH6R3ELL821MHB5D |
|---|---|
| Package/Case | 8 X 11.5 |
| Construction | Aluminum Cylindrical Can |
| Ripple Current | 900 mA |
| Lead Pitch For Radial | 3.5 mm |
| Operating Temperature | -40 to 105 °C |
| Package Dimensions | 8 x 11.5 mm |
| Tolerance | ±20 % |
| Mounting | Through Hole |
| Termination Style | Radial |
| Pin Count | 2 |
| Lead Finish | Tin|Bismuth |
| Equivalent Series Resistance | 0.062 Ohm |
| Lifetime | 6000 hr |
| Voltage(DC) | 6.3 Vdc |
| Supplier Package | Radial |
| Rad Hard | No |
| Leakage Current | 51.66@2Min uA |
| Maximum Processing Temperature | 260 °C |
| Capacitance Value | 820 uF |
| Product Diameter | 8 mm |
| Product Height | 11.5 mm |
| Replacement Part Number | PART-EKZH6R3ELL821MHB5D |
| Weight | Contact us |
| Country of Origin | - |
