Please contact us for more photos of ECA0JHG102B
| Part Number | ECA0JHG102B |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 566580 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Aluminum 1000uF 6.3V 20% (8 X 11.5mm) Radial 5mm 380mA 1000 hr 105\u00b0C Ammo Pack |
| Category | Capacitors |
| Family | Capacitor Aluminum |
| ROHS Compliant | Yes |
| MSL Level | ECA0JHG102B |
| Datasheet download |  ECA0JHG102B.pdf |
| Part Number | ECA0JHG102B |
|---|---|
| Leakage Current | 63@2Min uA |
| Capacitance Value | 1000 uF |
| Ripple Current | 380 mA |
| Max Processing Temp | 250 to 260 |
| Mounting | Through Hole |
| Lead Pitch For Radial | 5 mm |
| Lead Finish | Tin |
| Package/Case | 8 X 11.5 |
| Operating Temperature | -55 to 105 °C |
| Voltage(DC) | 6.3 V |
| Termination Style | Radial |
| Rad Hard | No |
| Tolerance | 20 % |
| Product Dimensions | 11.5 mm |
| Product Diameter | 8 mm |
| Product Height | 11.5 mm |
| Replacement Part Number | PART-ECA0JHG102B |
| Weight | Contact us |
| Country of Origin | - |
