Please contact us for more photos of ECA1AHG331
| Part Number | ECA1AHG331 |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 210430 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Aluminum 330uF 10V 20% (6.3 X 11.2mm) Radial Aluminum Cylindrical Can 2.5mm 200mA 1000 hr 105\u00b0C Bulk |
| Category | Capacitors |
| Family | Capacitor Aluminum |
| ROHS Compliant | Yes |
| MSL Level | ECA1AHG331 |
| Datasheet download |  ECA1AHG331.pdf |
| Part Number | ECA1AHG331 |
|---|---|
| Leakage Current | 33@2Min uA |
| Package/Case | 6.3 X 11.2 |
| Construction | Aluminum Cylindrical Can |
| Max Processing Temp | 250 to 260 |
| Mounting | Through Hole |
| Voltage(DC) | 10 V |
| Capacitance Value | 330 uF |
| Lead Finish | Tin |
| Operating Temperature | -55 to 105 °C |
| Termination Style | Radial |
| Lead Pitch For Radial | 2.5 mm |
| Rad Hard | No |
| Ripple Current | 200 mA |
| Tolerance | 20 % |
| Product Dimensions | 11.2 mm |
| Product Diameter | 6.3 mm |
| Product Height | 11.2 mm |
| Replacement Part Number | PART-ECA1AHG331 |
| Weight | Contact us |
| Country of Origin | - |
