Please contact us for more photos of ELL6RH2R7M
| Part Number | ELL6RH2R7M |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 199290 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Ind Choke Coil Shielded 2.7uH 20% 100KHz 1.8A Embossed Carrier T R |
| Category | Inductor |
| Family | Inductor Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | ELL6RH2R7M |
| Datasheet download |  ELL6RH2R7M.pdf |
| Part Number | ELL6RH2R7M |
|---|---|
| Product Dimensions | 6.9 x 6.5 x 3.1 mm |
| Max Processing Temp | 260 |
| Tolerance | 20 % |
| Test Frequency | 100 kHz |
| Package/Case | 6.9 X 6.5 X 3.1 |
| Protection Style | Shielded |
| Lead Finish | Tin |
| Product Depth | 6.5 mm |
| Product Height | 3.1 mm |
| Product Length | 6.9 mm |
| Replacement Part Number | PART-ELL6RH2R7M |
| Weight | Contact us |
| Country of Origin | - |
