Please contact us for more photos of P1173.223NLT
| Part Number | P1173.223NLT |
|---|---|
| Manufacturer | Pulse |
| Quantity in stock | 843930 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Ind Power Shielded Wirewound 22uH 20% 100KHz 3.8A T R |
| Category | Inductor |
| Family | Inductor Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | P1173.223NLT |
| Datasheet download |  P1173.223NLT.pdf |
| Part Number | P1173.223NLT |
|---|---|
| Inductance | |
| Impedance | |
| Maximum DC Resistance | |
| Core Material | |
| Maximum DC Current | |
| Maximum Self Resonant Frequency | |
| Rad Hard | No |
| Minimum Quality Factor | |
| Tolerance | 20 % |
| Technology | Wirewound |
| Test Frequency | 100 kHz |
| Type | Power |
| Operating Temperature | -40 to 130 °C |
| Product Dimensions | 12.24 x 12.24 x 8 mm |
| Package/Case | 12.24 X 12.24 X 8 |
| Protection Style | Shielded |
| Product Depth | 12.24 mm |
| Product Height | 8 mm |
| Product Length | 12.24 mm |
| Replacement Part Number | PART-P1173.223NLT |
| Weight | Contact us |
| Country of Origin | - |
