Please contact us for more photos of PG0083.601NLT
| Part Number | PG0083.601NLT |
|---|---|
| Manufacturer | Pulse |
| Quantity in stock | 524820 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Ind Power Wirewound 600nH 25% 100KHz 15A T R |
| Category | Inductor |
| Family | Inductor Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | PG0083.601NLT |
| Datasheet download |  PG0083.601NLT.pdf |
| Part Number | PG0083.601NLT |
|---|---|
| Maximum DC Resistance | |
| Minimum Quality Factor | |
| Core Material | |
| Maximum Self Resonant Frequency | |
| Rad Hard | No |
| Impedance | |
| Inductance | |
| Maximum DC Current | |
| Technology | Wirewound |
| Type | Power |
| Test Frequency | 100 kHz |
| Tolerance | 25 % |
| Operating Temperature | -40 to 95 °C |
| Product Dimensions | 6.8 x 6.8 x 4.2 mm |
| Package/Case | 6.8 X 6.8 X 4.2 |
| Product Depth | 6.8 mm |
| Product Height | 4.2 mm |
| Product Length | 6.8 mm |
| Replacement Part Number | PART-PG0083.601NLT |
| Weight | Contact us |
| Country of Origin | - |
