Please contact us for more photos of FTMH-105-02-F-DV
| Part Number | FTMH-105-02-F-DV |
|---|---|
| Manufacturer | Samtec |
| Quantity in stock | 484440 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Unshrouded Header HDR 10 POS 1mm Solder ST SMD Tube |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | FTMH-105-02-F-DV |
| Datasheet download |  FTMH-105-02-F-DV.pdf |
| Part Number | FTMH-105-02-F-DV |
|---|---|
| Contact Material | Phosphor Bronze |
| Pitch | 1 mm |
| Contact Plating | Gold Over Nickel |
| Housing Material | Liquid Crystal Polymer |
| Max Processing Temp | 260 |
| Lead Finish | Matte Tin |
| Rad Hard | No |
| Operating Temperature | -55 to 125 °C |
| MSL Level | 1 |
| Mounting | Surface Mount |
| Body Orientation | Straight |
| Termination Method | Solder |
| Gender | HDR |
| Housing Color | Black |
| Product Dimensions | 5 x 3.17 x 3.71 mm |
| Product Depth | 3.17 mm |
| Product Height | 3.71 mm |
| Product Length | 5 mm |
| Replacement Part Number | PART-FTMH-105-02-F-DV |
| Weight | Contact us |
| Country of Origin | - |
