Please contact us for more photos of B72580E1140S262
| Part Number | B72580E1140S262 |
|---|---|
| Manufacturer | TDK |
| Quantity in stock | 870270 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Var 14V 16V 800A 22 to 27V 1812 SMD Cardboard T R |
| Category | Circuit Protection |
| Family | Varistor |
| ROHS Compliant | Yes |
| MSL Level | B72580E1140S262 |
| Datasheet download |  B72580E1140S262.pdf |
| Part Number | B72580E1140S262 |
|---|---|
| Lead Style | Wraparound |
| Technology | Multi-Layer |
| Varistor Voltage | 14 to 22 V |
| Operating Temperature | -55 to 150 °C |
| Lead Finish | Tin Over Nickel |
| Pin Count | 2 |
| Rad Hard | No |
| Capacitance Value | 0.0056 uF |
| Product Dimensions | 4.5 x 3.2 x 2.5(Max) |
| Max Processing Temp | 260 |
| Supplier Package | 1812 |
| Size Code | 1812 |
| Product Depth | 3.2 mm |
| Product Height | 2.5(Max) mm |
| Product Length | 4.5 mm |
| Replacement Part Number | PART-B72580E1140S262 |
| Weight | Contact us |
| Country of Origin | - |
