Please contact us for more photos of B82472G4103M
| Part Number | B82472G4103M |
|---|---|
| Manufacturer | TDK |
| Quantity in stock | 580330 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Ind Power Shielded 10uH 20% 100KHz Ferrite 1.7A Blister T R |
| Category | Inductor |
| Family | Inductor Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | B82472G4103M |
| Datasheet download |  B82472G4103M.pdf |
| Part Number | B82472G4103M |
|---|---|
| Core Material | Ferrite |
| Tolerance | 20 % |
| Rad Hard | No |
| Max Processing Temp | 260 |
| Type | Power |
| Test Frequency | 100 kHz |
| Product Dimensions | 7.5 x 7.5 x 3.5 mm |
| Protection Style | Shielded |
| Lead Finish | Tin |
| MSL Level | 1 |
| Package/Case | 7.5 X 7.5 X 3.5 |
| Product Depth | 7.5 mm |
| Product Height | 3.5 mm |
| Product Length | 7.5 mm |
| Replacement Part Number | PART-B82472G4103M |
| Weight | Contact us |
| Country of Origin | - |
