Please contact us for more photos of IHLP5050FDER100MA1
| Part Number | IHLP5050FDER100MA1 |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 702460 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Ind High Current Shielded 10uH 20% 100KHz 10(Typ)A 5050 T R |
| Category | Inductor |
| Family | Inductor Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | IHLP5050FDER100MA1 |
| Datasheet download |  IHLP5050FDER100MA1.pdf |
| Part Number | IHLP5050FDER100MA1 |
|---|---|
| Pin Count | 2 |
| Protection Style | Shielded |
| Rad Hard | No |
| Package/Case | 5050 |
| Max Processing Temp | 260 |
| MSL Level | 1 |
| Product Dimensions | 13.259 x 12.9(Max) x 6.273(Max) |
| Tolerance | 20 % |
| Operating Temperature | -55 to 125 °C |
| Test Frequency | 100 kHz |
| Lead Finish | Tin Over Nickel |
| Supplier Package | 5050 |
| Product Depth | 12.9(Max) mm |
| Product Height | 6.273(Max) mm |
| Product Length | 13.259 mm |
| Replacement Part Number | PART-IHLP5050FDER100MA1 |
| Weight | Contact us |
| Country of Origin | - |
