Please contact us for more photos of PTN0805K1153FST1
| Part Number | PTN0805K1153FST1 |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 805630 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Res Thin Film 0805 115K Ohm 1% 1 5W \u00b1100ppm \u00b0C Molded SMD T R |
| Category | Resistor |
| Family | Resistor Fixed Single-Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | PTN0805K1153FST1 |
| Datasheet download |  PTN0805K1153FST1.pdf |
| Part Number | PTN0805K1153FST1 |
|---|---|
| Pin Count | 2 |
| Case Style | Molded |
| Product Dimensions | 2.03 x 1.27 x 0.84(Max) |
| Type | Thin Film |
| Rad Hard | No |
| Lead Finish | Matte Tin Over Nickel |
| Case Size | 0805 |
| Resistance Value | 115 kOhm |
| Power Rating | 0.2 W |
| Operating Temperature | -55 to 155 °C |
| Mounting | Surface Mount |
| Max Processing Temp | 260 |
| Supplier Package | 0805 |
| Tolerance | 1 % |
| Package Type | SMD |
| Termination Style | Wraparound |
| Temperature Coefficient | ±100 ppm/°C |
| Product Depth | 1.27 mm |
| Product Height | 0.84(Max) mm |
| Product Length | 2.03 mm |
| Replacement Part Number | PART-PTN0805K1153FST1 |
| Weight | Contact us |
| Country of Origin | - |
