Please contact us for more photos of WSL2816R0250FEH
| Part Number | WSL2816R0250FEH |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 390400 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Res Metal Film 2816 25m Ohm 1% 2W \u00b175ppm \u00b0C Molded SMD T R |
| Category | Resistor |
| Family | Resistor Fixed Single-Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | WSL2816R0250FEH |
| Datasheet download |  WSL2816R0250FEH.pdf |
| Part Number | WSL2816R0250FEH |
|---|---|
| Mounting | Surface Mount |
| Case Size | 2816 |
| Operating Temperature | -65 to 170 °C |
| Power Rating | 2 W |
| Temperature Coefficient | ±75 ppm/°C |
| Tolerance | 1 % |
| MSL Level | 1 |
| Supplier Package | 2816 |
| Product Dimensions | 7.1 x 4.2 x 0.635 |
| Resistance Value | 25 MOhm |
| Pin Count | 2 |
| Rad Hard | No |
| Lead Finish | Matte Tin Over Nickel |
| Case Style | Molded |
| Max Processing Temp | 260 |
| Termination Style | Wraparound |
| Product Depth | 4.2 mm |
| Product Height | 0.635 mm |
| Product Length | 7.1 mm |
| Product Weight | 118 mg |
| Replacement Part Number | PART-WSL2816R0250FEH |
| Weight | Contact us |
| Country of Origin | - |
