Please contact us for more photos of SRR1260-101M
| Part Number | SRR1260-101M |
|---|---|
| Manufacturer | Bourns |
| Quantity in stock | 794550 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Ind Power Shielded Wirewound 100uH 20% 100KHz 26Q-Factor Ferrite 1.7A T R |
| Category | Inductor |
| Family | Inductor Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | SRR1260-101M |
| Datasheet download |  SRR1260-101M.pdf |
| Part Number | SRR1260-101M |
|---|---|
| Technology | Wirewound |
| Max Processing Temp | 230 |
| Package/Case | 12.8 X 12.8 X 6.5 |
| Rad Hard | No |
| Tolerance | 20 % |
| Core Material | Ferrite |
| Operating Temperature | -40 to 125 °C |
| Test Frequency | 100 kHz |
| Type | Power |
| Protection Style | Shielded |
| MSL Level | 1 |
| Product Dimensions | 12.8 x 12.8 x 6.5 mm |
| Lead Finish | Tin |
| Impedance | |
| Inductance | |
| Maximum Self Resonant Frequency | |
| Maximum DC Resistance | |
| Maximum DC Current | |
| Minimum Quality Factor | |
| Product Depth | 12.8 mm |
| Product Height | 6.5 mm |
| Product Length | 12.8 mm |
| Replacement Part Number | PART-SRR1260-101M |
| Weight | Contact us |
| Country of Origin | - |
