Please contact us for more photos of FP1005R1-R22-R
| Part Number | FP1005R1-R22-R |
|---|---|
| Manufacturer | Eaton |
| Quantity in stock | 288140 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Ind Power Wirewound 220nH 10% 100KHz Ferrite 53A T R |
| Category | Inductor |
| Family | Inductor Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | FP1005R1-R22-R |
| Datasheet download |  FP1005R1-R22-R.pdf |
| Part Number | FP1005R1-R22-R |
|---|---|
| Package/Case | 10.2 X 7 X 4.95 |
| Operating Temperature | -40 to 125 °C |
| Rad Hard | No |
| Tolerance | 10 % |
| Core Material | Ferrite |
| Technology | Wirewound |
| Maximum Self Resonant Frequency | |
| Inductance | |
| Maximum DC Resistance | |
| Maximum DC Current | |
| Impedance | |
| Minimum Quality Factor | |
| Max Processing Temp | 250 |
| Type | Power |
| Product Dimensions | 10.2 x 7 x 4.95 mm |
| Test Frequency | 100 kHz |
| Product Depth | 7 mm |
| Product Height | 4.95 mm |
| Product Length | 10.2 mm |
| Replacement Part Number | PART-FP1005R1-R22-R |
| Weight | Contact us |
| Country of Origin | - |
