Please contact us for more photos of LQG15HS4N7S02D
| Part Number | LQG15HS4N7S02D |
|---|---|
| Manufacturer | Murata Manufacturing |
| Quantity in stock | 133470 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Ind RF Chip Multi-Layer 4.7nH 0.3nH 100MHz 8Q-Factor Air 300mA 0402 Paper T R |
| Category | Inductor |
| Family | Inductor Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | LQG15HS4N7S02D |
| Datasheet download |  LQG15HS4N7S02D.pdf |
| Part Number | LQG15HS4N7S02D |
|---|---|
| Lead Finish | Matte Tin |
| Minimum Quality Factor | 8@100MHz |
| Core Material | Air |
| Operating Temperature | -55 to 125 °C |
| Technology | Multi-Layer |
| Test Frequency | 100 MHz |
| Product Dimensions | 1.05 x 0.55 x 0.55 mm |
| Package/Case | 0402 |
| Max Processing Temp | 260 |
| Type | RF Chip |
| Rad Hard | No |
| Tolerance | 0.3 nH |
| Product Depth | 0.55 mm |
| Product Height | 0.55 mm |
| Product Length | 1.05 mm |
| Replacement Part Number | PART-LQG15HS4N7S02D |
| Weight | Contact us |
| Country of Origin | - |
