BAS40-04W115 Nexperia

BAS40-04W115 Images

Please contact us for more photos of BAS40-04W115

Part Number BAS40-04W115
Manufacturer Nexperia
Quantity in stock 418540 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Diode Schottky 40V 0.12A 3-Pin SC-70 T R
Category Discrete Semiconductor
Family Diode
ROHS Compliant Yes
MSL Level BAS40-04W115
Datasheet download BAS40-04W115.pdf
Request Quotation for BAS40-04W115

BAS40-04W115 Specifications

Part Number BAS40-04W115
Pin Count 3
Rad Hard No
Mounting Surface Mount
Peak Forward Voltage [email protected] V
Lead Finish Tin
MSL Level 1
Configuration Dual Series
Operating Temperature -65 to 150 °C
Peak Non-Repetitive Surge Current 0.2 A
Peak Average Forward Current 0.12 A
Max Processing Temp 260
Product Dimensions 2.2 x 1.35 x 1 mm
Type Schottky Diode
Supplier Package SC-70
Peak Reverse Current 10 uA
Peak Reverse Repetitive Voltage 40 V
Package 3SC-70
Replacement Part Number PART-BAS40-04W115
Weight Contact us
Country of Origin -
