B82442H1225K TDK

B82442H1225K Images

Please contact us for more photos of B82442H1225K

Part Number B82442H1225K
Manufacturer TDK
Quantity in stock 342210 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Ind High Current Chip Molded Wirewound 2.2mH 10% 252KHz 30Q-Factor Ferrite 75mA 2220 Blister T R
Category Inductor
Family Inductor Surface Mount
ROHS Compliant Yes
MSL Level B82442H1225K
Datasheet download B82442H1225K.pdf
Request Quotation for B82442H1225K

B82442H1225K Specifications

Part Number B82442H1225K
Technology Wirewound
Core Material Ferrite
Rad Hard No
Tolerance 10 %
Max Processing Temp 260
Test Frequency 252 kHz
Protection Style Molded
Type High Current Chip
MSL Level 1
Product Dimensions 5.9 x 5.3 x 5.3 mm
Lead Finish Tin
Package/Case 2220
Product Depth 5.3 mm
Product Height 5.3 mm
Product Length 5.9 mm
Replacement Part Number PART-B82442H1225K
Weight Contact us
Country of Origin -
